INDOOR LUMINAIRES
LN29N CEILING LIGHT
공유
복사!
LN29N CEILING LIGHT
모델: LN29N 170/12W; LN29N 170x170/12W; LN29N 220/18W; LN29N 220x220/18W; LN29N 300/24W; LN29N 300x300/24W; LN29N DM 170/12W; LN29N DM 170x170/12W; LN29N DM 220/18W; LN29N DM 220x220/18W; LN29N DM 300/24W; LN29N DM 300x300/24W
Power (W)
12/18/24/50/60
Voltage (V)
100 ÷ 277/120/220÷240
Power factor
0.5/0.9
Luminous efficacy (lm/W)
68/72/75/80/83
CRI (Ra)
80
Life span (hrs)
25,000
Beam angle
120
CCT (K)
3000/4000/5000/6500
SHOW ALL
null
자격증
최신 가격
최신 가격
특징
명세
다운로드
특징
명세
다운로드
PRODUCT FEATURES
High-quality LEDs provided by Samsung/ Seoul Semiconductor/ Nichia/ Lumiled with excellent performance
LEDs with optical lens to ensure an evenly distributed beam of light
PC housing and PC cover with high lighting transmittance and desired lighting distribution
Flicker-free
CE, KC certified
Long lifespan: 25,000 hours, saving the maintenance cost
Options:
1 CCT
3-color changeable CCT (adjust by wall switch)
APPLICATIONS
Home, office, corridor, aisle, supermarket, shopping mall, exhibition hall, etc.
PRODUCT DETAILS
PRODUCT SPECIFICATIONS
Model
Dimension
LxWxH (mm)
Power
(W)
Voltage (V)
Power factor
Luminous flux
(lm)
Luminous efficacy
(lm/W)
CCT (K)
CRI (Ra)
Beam angle (°)
Lifespan
(hrs)
LN29N 170/12W
160x43
12
120/220÷240/100÷277
0,5/0,9
810/900
68/75
3000/4000/6500
80
120
25000
LN29N 170x170/12W
160x160x43
12
120/220÷240/100÷277
0,5/0,9
810/900
68/75
3000/4000/6500
80
120
25000
LN29N 220/18W
220x43
18
120/220÷240/100÷277
0,5/0,9
1300/1450
72/80
3000/4000/6500
80
120
25000
LN29N 220x220/18W
220x220x43
18
120/220÷240/100÷277
0,5/0,9
1300/1450
72/80
3000/4000/6500
80
120
25000
LN29N 300/24W
300x43
24
120/220÷240/100÷277
0,5/0,9
1800/2000
75/83
3000/4000/6500
80
120
25000
LN29N 300x300/24W
300x300x43
24
120/220÷240/100÷277
0,5/0,9
1800/2000
75/83
3000/4000/6500
80
120
25000
LN29N DM 170/12W
160x43
12
120/220÷240/100÷277
0,5/0,9
810/900
68/75
3CCT 3000-4000-6500
80
120
25000
LN29N DM 170x170/12W
160x160x43
12
120/220÷240/100÷277
0,5/0,9
810/900
68/75
3CCT 3000-4000-6500
80
120
25000
LN29N DM 220/18W
220x43
18
120/220÷240/100÷277
0,5/0,9
1300/1450
72/80
3CCT 3000-4000-6500
80
120
25000
LN29N DM 220x220/18W
220x220x43
18
120/220÷240/100÷277
0,5/0,9
1300/1450
72/80
3CCT 3000-4000-6500
80
120
25000
LN29N DM 300/24W
300x43
24
120/220÷240/100÷277
0,5/0,9
1800/2000
75/83
3CCT 3000-4000-6500
80
120
25000
LN29N DM 300x300/24W
300x300x43
24
120/220÷240/100÷277
0,5/0,9
1800/2000
75/83
3CCT 3000-4000-6500
80
120
25000
Capacity:
3.2 million pieces per year
Customizable:
Power (50/60W), Voltage (120/220÷240/100÷277), PF, lm/W, CCT (3000/4000/5000/6500K), lifespan, etc.
LUMINOUS INTENSITY DISTRIBUTION
PACKING AND TRANSPORTATION
Type of lamps
Quantity in master box (pcs)
Estimated quantity/20'DC (pcs)
Estimated quantity/40'HC (pcs)
LN29N 12W
8
19 032
43 712
LN29N 18W
8
10 952
25 152
LN29N 24W
6
6 546
15 030
Customizable according to customer’s request
Exported markets: South Korea, EU, etc.
CE
다운로드
KC
다운로드
RoHS
다운로드
LN29N CEILING LIGHT
다운로드
